Air Lift Performance 3H

  • $1,735.00

Looking for the ultimate in ride control? Want to put your car on the ground at shows but want the ability to lift it back up to drive home? Do speed bumps or pulling into driveways make you cringe? Or do you just want to fine tune your suspension for the ultimate in ride comfort?

If you answered yes to any of these, or all of them, then Air Lift air ride is for you! With the flip of a switch, you can raise your car to ride height, then when your parked, flip the switch again and your back on the pavement.

30 levels of damping adjustment allow you go from race car stiff to a comfortable ride with the twist of a knob. Top all that off with a T6061 aluminum adjustable camber plate covered in a anodized red hue. All this equates to performance handling, killer ride quality and the ability to slam the front end 4.8” from stock.

The rear suspension was treated with double-bellows air springs in the place of the factory coil spring, giving you a 5.8” drop from original stock height. They also replaced the factory OEM control arms with their industry-first, CNC laser-cut, robotically welded lower control arms to deliver maximum drop and cornering ability. To help keep things under control, they have added monotube shocks with 30 levels of damping adjustability to match the front—for the ultimate in handling and ride comfort!

In order to bring to market the most durable air suspension possible, Air Lift Performance tortured the components of this kit to one million cycles (equivalent to approximately 100,000 miles) on their hydraulic test rig at temperatures from -30 deg F to 150 deg F. Couple this test lab work with thousands of miles of on-road testing—not to mention the one-year manufacturer’s warranty—and this is a kit you can count on to handle whatever the road throws down!

Isn’t it time you had the option of getting a killer lowered look without giving up ride quality or handling and having to worry about scraping your ride? Ditch the springs and get to an entire new level of low.

Performance Series Front Suspension Kit:

(2) Fully Threaded, Damping Adjustable Air Struts with Double Bellow Bags
(2) Red Anodized Camber Plates
(2) Damping Adjuster Knobs
(2) Stainless Steel braided leader lines
(4) DOT Approved Fittings- Both 1/4 PTC and 3/8 PTC
Spanner Tool
Anodized end caps
Corrosion-resistant paint on strut bodies
All Required Mounting Hardware
1 Year Manufacturer Warranty
Detailed Installation Manual with Pictures
Performance Series Rear Kit:

(2) Fully Threaded, Damping Adjustable Struts
(2) Rear Air Springs
(2) Sets of Air Spring Mounting Brackets
(4) DOT Approved Fittings- both 1/4 PTC and 3/8 PTC
Anodized end caps
All Required Hardware
1 Year Manufacturer Warranty
Detailed Installation Manual with Pictures
Air Lift Manual Management Includes:

(4) Manual Paddle Valves with Stainless Steel Mounting Plate
4 Gallon Raw Aluminum Tank
Viair 380C compressor
40amp Relay for your compressor
Connectors and Power Wire for making a Compressor Relay harness
Inflation Valve
145/175 PSI Pressure Switch
Air Line Cutter Tool
Bundle of 1/4" Air Line
(2) PTC Union Y Fittings
Gauge Kit:

(2) Air Lift Dual Needle Pressure Gauges
Connectors and Power Wire for Gauge bulbs
All Fittings Required to Connect to Air Supply
AIR LIFT SUPPORT/DISCLAIMER Because of the extremely custom nature of air ride suspensions, no installation support is available through Carrot Top Tuning's customer service lines. Though supplied with installation instructions, modifications will need to be made to the body, suspension, and other components of the car including running air lines and installing air bags. Suspension modifications may be needed on a case to case basis. If the included instructions are not sufficient to install your Air Lift kit, technical support is available through Air Lift's technical support lines at (800)- 248-0892. Additionally, all warranty claims and information from failed components are also handled directly through Air Lift on a case by case basis. (This is not a direct bolt in kit. If it seems that it may exceed your skill level, please consider professional installation.)
